AGM RattlerV2 25-384 Thermal Rifle Scope 20mK 384x288 (50 Hz) 25mm Lens

ITEM NUMBER:
AX314204550204R231
UPC:
810027777317
BRAND:
AGM
MFG PRODUCT #:
314204550204R231
SPECIFICATIONS
BATTERY COUNT:
2
BATTERY RUN TIME:
UP TO 11.5 HOURS (25 DEG C WITH HOTSPOT OFF)
BATTERY TYPE:
RECHARGEABLE
BRAND:
AGM
BRAND FAMILY:
RATTLERV2
CA PROP 65:
YES
COLOR:
BLACK
CONDITION:
NEW
COUNTRY OF ORIGIN:
USA
MATERIAL:
ALUMINUM
MICROPHONE:
YES
OPTICS APP SUPPORT:
AGM CONNECT
OPTICS CLASS:
THERMAL IMAGING
OPTICS FINISH:
MATTE
OPTICS LENGTH:
8.5"
OPTICS MOUNTING SYSTEM:
ADM QD
OPTICS OBJECTIVE:
25
OPTICS SHOCKPROOF:
YES
OPTICS TYPE:
THERMAL RIFLE SCOPE
THERMAL BLUETOOTH:
NO
THERMAL BORESIGHT ADJ:
DIGITAL CONTROLLED
THERMAL CALIBER RATING:
308 WIN
THERMAL DETECTOR TYPE:
12UM VOX UNCOOLED FOCAL PLANE ARRAY
THERMAL DIGITAL ZOOM:
2X-16X
THERMAL DIOPTER ADJ:
-5/+5
THERMAL DISPLAY / MONITOR TYPE:
OLED
THERMAL DISPLAY RESOLUTION:
384 X 288
THERMAL EYE RELIEF:
45MM
THERMAL FLAT FIELD CORRECTION:
AUTO / MANUAL / EXTERNAL CORRECTION
THERMAL FOV DEG:
10.5° X 7.9°
THERMAL HUMAN DETECT RANGE:
1200 YDS
THERMAL IMAGING PALETTES:
WHITE BLACK RED HOT FUSION
THERMAL MAGNIFICATION:
2.5X
THERMAL MULTI-LANGUAGE MENU:
YES
THERMAL NETD:
<20 MK
THERMAL OBJECTIVE LENS (FOCAL LENGTH):
25MM F/1.0
THERMAL OPERATING TEMPERATURE:
-30°C TO +55°C (-22°F TO +131°F)
THERMAL OPTICS WI-FI:
YES
THERMAL PIP MODE:
YES
THERMAL POWER SUPPLY:
5 VDC/2 A USB TYPE-C
THERMAL RANGEFINDER:
STADIAMETRIC
THERMAL RECORDING TYPE:
ON-BOARD VIDEO AND AUDIO
THERMAL RETICLE:
10 RETICLES / 4 COLORS / ON/OFF
THERMAL SCENE MODES:
COLD / WARM
THERMAL SENSOR FRAME (REFRESH) RATE:
50 HZ
THERMAL SENSOR PIXEL INTERVAL:
12 UM
THERMAL SENSOR RESOLUTION:
384 X 288
THERMAL SNAPSHOT CAPTURE:
YES
THERMAL STANDBY MODE:
YES
THERMAL STORAGE:
BUILT-IN EMMC (16 GB)
THERMAL TEMP SPOT TRACKING:
YES
THERMAL VIDEO RECORDING RESOLUTION:
YES
WARRANTY:
MFG 3 YEAR
WATERPROOF:
IP67
WEIGHT:
1.1 LB
DESCRIPTION

The AGM Rattler V2 25-38 thermal scope features a 25mm Germanium lens, a 384 x 288 resolution thermal sensor, and a 2x base magnification with a detection range of up to 1200 m/yd. Out of the two 384-resolution options, this thermal scope has a lower base magnification and a wider Field of View  (10.5° × 7.9°  or 55 ft @ 100 yds) providing extensive area coverage while scanning

The RattlerV2 25-384 includes features familiar to AGM Rattler users, with some additional game-changing improvements such as an upgraded battery compartment that accommodates a rechargeable battery extending run time to 11 hours and a new 12-micron thermal sensor that has the highest sensitivity rating (sub-20 mk) on the market.

Notable features include Shot Activated Recording, a simplified menu layout, and 10 reticle options with multiple zeroing profiles for various calibers and rifles. The scope also comes with a custom ADM QD Mount for easy removal and reattachment, Wi-Fi hotspot connectivity through the AGM app, a user-friendly, raised 5-button layout for easy navigation, even with gloves, and much more!

Features:

  • Upgraded Scope Body Design
  • 25mm Germanium lens
  • 384 x 288 resolution thermal sensor
  • 2x base magnification
  • 2× - 16× digital zoom
  • Detection range up to 1200 m/yd
  • Field of View at 10.5° × 7.9° (55 ft @ 100 yds)
  • 50 Hz Refresh Rate
  • Enhanced focus ring with short throw
  • Upgraded Lens Cap
  • Rechargeable battery with up to 11 hours of run time
  • Shot Activated Recording
  • Video and Audio Recording
  • Simplified menu layout for ease of use
  • 10 different reticle options
  • Multiple zeroing profiles for various calibers and rifles
  • Custom ADM QD Mount for easy scope removal and reattachment
  • Wi-Fi hotspot for connectivity with the AGM app
  • Raised 5-button layout for easy navigation, even with gloves
