Home > Catalog > Pard Ocelot Thermal Imaging Rifle Scope with LRF 640 Zoom 25/50mm Lens

Pard Ocelot Thermal Imaging Rifle Scope with LRF 640 Zoom 25/50mm Lens

ITEM NUMBER:

PDOC6Z2550LRF

UPC:

850050408673

BRAND:

Pard

MFG PRODUCT #:

OC6Z-25/50/LRF

SPECIFICATIONS

BATTERY COUNT:

BATTERY RUN TIME:

6 HR

BATTERY TYPE:

LI-ION 21700*1

BRAND:

PARD

BRAND FAMILY:

OCELOT

CA PROP 65:

YES

COLOR:

BLACK

CONDITION:

NEW

COUNTRY OF ORIGIN:

CHINA

MATERIAL:

ALUMINUM

MICROPHONE:

YES

OPTICS ACTIVATION MODES:

RECOIL ACTIVATED

OPTICS APP SUPPORT:

PARDVISION 2

OPTICS CLASS:

THERMAL IMAGING

OPTICS FINISH:

ANODIZED

OPTICS LENGTH:

6.4"

OPTICS MOUNTING SYSTEM:

INTEGRATED WEAVER-STYLE

OPTICS OBJECTIVE:

25/50

OPTICS SHOCKPROOF:

YES

OPTICS TYPE:

THERMAL LASER RANGEFINDING RIFLE SCOPE

THERMAL BLUETOOTH:

THERMAL BORESIGHT ADJ:

DIGITAL CONTROLLED

THERMAL DETECTOR TYPE:

12UM

THERMAL DIGITAL ZOOM:

2X 4X 6X 8X

THERMAL DISPLAY / MONITOR TYPE:

IPS

THERMAL DISPLAY RESOLUTION:

800 X 800

THERMAL EYE RELIEF:

100MM

THERMAL FOV DEG:

14.0° X 7.0°

THERMAL HUMAN DETECT RANGE:

1200 / 2600 YDS

THERMAL IMAGING PALETTES:

6 COLOR

THERMAL MAGNIFICATION:

2.5X

THERMAL MULTI-LANGUAGE MENU:

YES

THERMAL NETD:

<20 MK

THERMAL OBJECTIVE LENS (FOCAL LENGTH):

25MM / 50MM

THERMAL OPERATING TEMPERATURE:

-22 TO 131°F / -30 TO 55°C

THERMAL OPTICS WI-FI:

YES

THERMAL PIP MODE:

YES

THERMAL POWER SUPPLY:

USB-C EXTERNAL

THERMAL RANGEFINDER:

1200 YD

THERMAL RECORDING TYPE:

ON-BOARD VIDEO AND AUDIO & STILL IMAGES

THERMAL RETICLE:

MULTIPLE COLORS AND PATTERNS

THERMAL SCENE MODES:

CITY/RAIN/FOREST

THERMAL SENSOR FRAME (REFRESH) RATE:

50 HZ

THERMAL SENSOR PIXEL INTERVAL:

12 UM

THERMAL SENSOR RESOLUTION:

640 X 512

THERMAL STANDBY MODE:

YES

THERMAL TEMP SPOT TRACKING:

YES

THERMAL VIDEO RECORDING RESOLUTION:

768X768

WARRANTY:

MFG 3 YEAR LIMITED

WATERPROOF:

IP67

WEIGHT:

25 OZ

DESCRIPTION

Ocelot Zoom: Switch between the 25mm lens that offers a 1.3x base magnification and the 50mm lens that offers a 2.5x base magnification. You can view magnified HD images without distortion using the 2-8X digital zoom. Switch between the two lenses by adjusting the main lens ring back and forth and focus with the knob on the top of the ring. An important technical specification is the Noise Equivalent Temperature Difference (NETD) rating. This is one of the most important technical specifications for any thermal device. NETD indicates how small of a thermal difference the device can detect in the environment. The Ocelot Zoom is an industry leading ≤20mK. The Ocelot Zoom features a cutting-edge uncooled Vanadium Oxide640x512 sensor that delivers clear images and crisp target details. It also features a 12µm pixel pitch which is a measurement of the distance between the pixels of the digital image.

25mm FOV: providing a wider field of view.

50mm FoV: providing a long distance shooting game.
